If you have read Function pointers, you may be wondering about how you might use function pointers to call the member functions of structs and classes. And you would be right to wonder. Regular function pointers will not work. What we need for this task is member function pointers, aka pointers to members functions. Strictly speaking, this only relates to non-static member functions, since static member functions do work with regular function pointers.

Pointers to member functions are quite strange beasts which are only superficially similar to regular function pointers. I think they are one of the nifty cool features of C++, but sadly they seem to be not well understood by a lot of C++ developers.

This article builds on the previous article on function pointers, and aims to explain member function pointers a little, and how they can be used to integrate C++ code with C callback functions.

How member functions are implemented

To understand member function pointers and why they are so different from regular function pointers, it may help to understand a little bit about how classes are actually implemented by the compiler. Suppose we have some code that looks like this:

// Simple class with a few member functions.
class Thing
{
public:
    // Constructor.
    Thing(int offset); // : m_offset{offset} {}
    // Non-static member functions.
    int add(int a, int b); // { return a + b + m_offset; }
    int mul(int a, int b); // { return a * b + m_offset; }
    // Static member function.
    static int div(int a, int b); // { return a / b; }
private:
    int m_offset;
};

Thing::Thing(int offset)
: m_offset{offset}
{
}

int Thing::add(int a, int b)
{
    return a + b + m_offset;
}

int Thing::mul(int a, int b)
{
    return a * b + m_offset;
}

int Thing::div(int a, int b)
{
    return a / b;
}

// Using the class.
int test()
{
    Thing t{12};
    return t.add(13, 14);
}

I could have inlined the member functions inside the class to make the code shorter (see comments), but wanted it to closely resemble the C that follows. The code is implemented (more or less) by the compiler as if you had written C something like this:

// Simple class with a few associated functions.
// Not official C as no typedef 'tag' malarky here.
struct Thing
{
    // This throws away the notion of 'private'
    int m_offset;
};

void Thing_Thing(Thing* this, int offset)
{
    this->m_offset = offset;
}

int Thing_add(Thing* this, int a, int b)
{
    return a + b + this->m_offset;
}

int Thing_mul(Thing* this, int a, int b)
{
    return a * b + this->m_offset;
}

int Thing_div(int a, int b)
{
    return a / b;
}

int test()
{
    Thing t;
    Thing_Thing(&t, 12);
    return Thing_add(&t, 13, 14);
}

The compiler automatically inserts an additional parameter called this which holds a pointer to the instance of the object on which the function is called. That is to say, my_thing.add(13, 19) would effectively be implemented as Thing_add(&my_thing, 13, 19). It’s more complicated when there are virtual functions or multiple inheritance, but that’s the basic idea. [Interestingly, this means you can call a member function without an actual object: a null pointer is sufficient – the compiler doesn’t care as long as the pointer has the correct type. this would be nullptr or, worse, uninitialised. Don’t do this on purpose. :)]. this is a keyword in C++, so the “as if” code won’t actually compile unless you replace it with another name.

The made up “as if” function names are not that far from reality. The compiler will invent a name each the function based on the namespace, the class name, the parameter types, and other factors. This is what we know as name-mangling. To you it looks like Thing::add; to the linker it looks like _ZN5Thing3addEii (from GCC), or something equally ugly. There is no ambiguity. Incidentally, this is also how function overloading works: different signatures lead to different names. Debuggers usually do a good job of de-mangling the names so you don’t have to scratch your head too much.

So, in principle, a member function pointer is just like a regular function pointer. The member function pointer for Thing::add() can be imagined to hold the address of Thing_add(). But unfortunately this is not enough information to make the call work.

• The key thing to note is that when we use the member function pointer we will need somehow to supply a value for the this parameter in addition to values for the other parameters to the function. This is very different from plain function pointers.
• And it gets more complicated when virtual functions and multiple inheritance are involved. I thought it was quite something when I discovered that a pointer to a virtual member function will do the right thing.
• I don’t know this, but the compiler will presumably need to know which class the function pointer relates to, Thing in this case, so that functions of other classes with similar signatures can be rejected as being of different types (I’m glossing over the type of this here). I captured the class name in the “as if” function names, but I imagine the compiler wants a link to some detailed type info or something.
  • Note that a pointer to a member function of some class is also usable with matching member functions of derived classes.

In truth, the way member function pointers are actually represented internally is implementation defined. That means each compiler can do whatever it wants, so long as it works. In many cases, they may actually be simple function pointers as suggested above. Or they might be structs with several data members containing all the necessary information, or something completely different. They are black boxes that we will soon learn how to use, but shouldn’t look inside. The sizes of member function pointers can even be different for different classes, which was an unpleasant surprise when I found out. It’s really best not to think of them as holding meaningful information or function addresses at all. Just treat them as opaque gizmos that you can somehow use to invoke a member function of a particular object.

Note that the static member function Thing::div() does not have a this parameter. It doesn’t need one because static functions aren’t tied to any particular instance of a class, but can be called on any object, or even without any object. If you did want to give a static function access to a particular object, you’d have to add a Thing* parameter of your own. For this reason, static member functions can be used with regular function pointers.

Aliases for member function pointer types

Following on from the discussion of signatures for regular function pointers here, the signature of a member function pointer is very similar, but includes the type of the class or struct as well. Suppose we have the following class:

class Gadget
{
public:
    void foo(int, double);
    void bar(int, double);
};

In this code Gadget::foo() and Gadget::bar() have the same signature, and it is void (Gadget::*)(int, double). This is basically identical to the signature for a free function which takes int and double arguments and returns void, but also includes the name of the class and the scope resolution operator before the star. Declaring variables of member function pointers types is straightforward, but ugly. Invoking them to call functions is worse:

// Gadget::foo() is a function.
void Gadget::foo(int arg1, double arg2)
{
     // ...
}

// mem_fun_ptr is a member function pointer.
void (Gadget::*mem_fun_ptr)(int, double);

// mem_fun_ptr now hold the "address" of Gadget::foo().
mem_fun_ptr = &Gadget::foo;

Gadget gadget;
// Calls Gadget::foo(). See below.
(gadget.*mem_fun_ptr)(1, 2);

We can declare member function pointer types (that is, aliases for the function signature) in much the same ways as for regular function pointers.

Typedef

// Direct variable declaration - avoid!!
// mem_fun_ptr is a variable: it is a
// pointer to member function of type
// void (Gadget::*)(int, double).
void (Gadget::*mem_fun_ptr)(int, double);

// C style type alias - avoid.
// OldMemFunPtr is an alias for the pointer to
// member function type void (Gadget::*)(int, double).
typedef void (Gadget::*OldMemFunPtr)(int, double);

Type alias (C++11)

// C++11 style type alias - preferred.
// NewMemFunPtr is equivalent to OldMemFunPtr.
using NewMemFunPtr = void (Gadget::*)(int, double);

Trailing return type (C++11)

// C++11 style type alias - trailing return type.
// NewMemFunPtr is equivalent to OldMemFunPtr.
using TrailingMemFunPtr = auto (Gadget::*)(int, double) -> void;

As with regular function pointers, member function pointers can appear in the same places as other data types: as local variables, member variables, in containers, and so on. Aside from calling functions, compared for equality (or non-equality), but few other operators make any sense with them, including other relational operators, and probably won’t compile.

Using a member function pointer variable

So far we have covered what member function pointers are and how to alias them with simple names to hide the rather unpleasant syntax, but we haven’t actually used them for much function pointing. This is very simple: you just assign the function pointer with address of a function, or the value of another function pointer, and then you use the function pointer to call the function of whose address it currently holds:

class Maths
{
    void Maths::square(int x)
        { std::cout << x << " squared is " << (x*x); }
    void Maths::cube(int x)
        { std::cout << x << " cubed is " << (x*x*x); }
};

// Create an alias for the function pointer.
using MemFuncPtr = void (Maths::*)(int);

int test()
{
    Maths  maths;

    MemFuncPtr ptr = &Maths::cube;
    // Read as maths.function(3) where
    // "function" is "deference ptr".
    (maths.*ptr)(3); // Calls cube(3)

    // Call with a Maths object
    ptr = &Maths::square; // & mandatory
    (maths.*ptr)(5); // Calls square(5)

    MemFuncPtr ptr2 = ptr;
    (maths.*ptr2)(5); // Calls square(6)

    // Call with a pointer to a Maths object
    Maths* maths_ptr = &maths;
    // Read as maths_ptr->function(6) where
    // "function" is "deference ptr".
    (maths_ptr->*ptr2)(6); // Calls square(6)
}

Going through some of this in order:

• MemFuncPtr is an alias for member function pointers with the signature void (Maths::*)(int).
• We create an instance maths of the class Maths and take its address in a pointer.
• We declare a member function pointer as take the address of Maths::cube. Note that the & is always required when taking the address of member functions, which is different from non-member functions.
• Next comes one of the two least well understood of all C++ operators: .*. It really isn’t all that bad, but could stand some explanation:
  • Remember when I said earlier that we need a way to pass the this pointer to the imaginary function implementation we are calling? That is precisely what this operator does.
  • I find it helpful to split the operator into two parts in my mind: the star just means “dereference the function pointer to give us a function”. This is analogous to the way dereferencing a data pointer gives us data. [Actually a reference to data, but ignore that.]
  • And then the other part of the operator, the dot, has exactly the same meaning it would have if we were calling a member function directly rather than through a function pointer.
  • The parentheses around (maths.*ptr) are required for reasons of operator precedence. This is unfortunate, as it makes the function call look weird and ugly. Shame, but that’s how it is.
• Later we take the address of the object maths and then use the data pointer maths_ptr to invoke a member function pointer. This uses the other scary member access operator: ->*. As before, it may be simpler to interpret this in two parts. As before, the parentheses are required.

Note that like regular function pointers, member function pointers have distinct types (including the name of the class), and cannot to assigned to pointers of other types (except that member of derived classes can be used with pointers to members of base classes). I’m not sure I would even cast them: what meaning would the result have?

And that’s it. Member function pointers are actually kind of cool, and not nearly as arcane as is commonly believed. There are some complexities in their implementation for virtual functions and in the presence of multiple inheritance, but this has no impact on how they are used in your code.

Interfacing member functions with C

Sadly it is not possible to pass member function pointers to C APIs. C simply has no concept of what they are, and can only handle pointers to free functions (and static member functions). There are a few simple things we can do interface our C++ with C.

C to member function callbacks – version 1

So… you are writing your application in C++ but have to pass a callback to some C API. You would really like it if it would call a member function of a particular object. There is a simple way to do this: create an intermediate function to act as a trampoline.

using Callback = void (*)(int x, void* context);
void c_api_set_callback(Callback cb, void* context);

struct Foo
{
    Foo();
    void alpha(int x);
    void beta(int x);
    void gamma(int x);
    void delta(int x);
};

// Trampoline signature matches what the C expects.
void call_foo_alpha(int x, void* context)
{
    // We know this is a safe cast.
    // Translate into a member function call.
    auto foo = static_cast<Foo*>(context);
    foo->alpha(x);
}

// Constructor sets up the callback.
Foo::Foo()
{
    // Pass pointer to this object as context.
    c_api_set_callback(call_foo_alpha, this);
}

It is very simple and it works very well indeed. A problem with this approach is that we would need to write individual trampoline functions for each member we wanted to use a callback function, even though they all have the same signature. This is not ideal.

Note also that the “trampoline” function needs to be able to see the members of the class it needs to use. They must be public, or it must be a friend. Alternatively, the trampoline could be a static member function of the class.

C to member function callbacks – version 2

There is a slightly better way, which makes use of a member function pointer (that’s why we’re here, after all) and allows us to write only one trampoline function for all the matching members.

The thing about member function pointers is that they are known at compile time. The type is known at compile time, obviously, but so are the specific values (however they might be implemented) corresponding to each particular member function. This means that we can use a member function pointer as a non-type template parameter. Like this:

// Alias for a member function pointer.
using MemFuncPtr = void (Foo::*)(int);

// The trampoline is now a template parameterised on
// a particular member function pointer.
template <MemFuncPtr mem_func_ptr>
void call_foo_member(int x, void* context)
{
    // And use the member function pointer.
    auto foo = static_cast<Foo*>(context);
    (foo->*mem_func_ptr)(x);
}

Foo::Foo()
{
    // Instantiate the template for several different members.
    c_api_set_callback(call_foo_member<&Foo::alpha>, this);
    c_api_set_callback(call_foo_member<&Foo::beta>, this);
    c_api_set_callback(call_foo_member<&Foo::gamma>, this);
    c_api_set_callback(call_foo_member<&Foo::delta>, this);
}

This is great, but remember that templates are code generators. By instantiating the template four times in Foo::Foo(), we generated four different versions of the code, which all differ just by which member function they call (you can verify this by copying the code into Compiler Explorer). Four virtually identical functions! Is it bloat? Well, the functions are very small. Is it justified? There isn’t really another way, and the template saved us from some repetitive and error prone typing. As always with templates, if you actually need the code they generate, you need it. You would have written it by hand anyway. Or you might find another way to get the same result.

C to member function callbacks – version 3

The little template trampoline is nice, but we can do a little better still. At the moment the trampoline is only useful for members of Foo. It would be really useful if we had a single implementation which could always be used, regardless of which class the target member function belonged to. I suspect you know what’s coming: we can convert Foo itself into a template parameter. Like this:

// Template the member function pointer type alias.
template <typename Class>
using MemFuncPtr = void (Class::*)(int);

// Add Class to the template trampoline.
template <typename Class, MemFuncPtr<Class> mem_func_ptr>
void call_member(int x, void* context)
{
    auto obj = static_cast<Class*>(context);
    (obj->*mem_func_ptr)(x);
}

Foo::Foo()
{
    // Pass pointer to this object as context.
    c_api_set_callback(call_member<Foo, &Foo::alpha>, this);
}

struct Bar
{
    Bar();
    void something(int x);
};

Bar::Bar()
{
    // Assume Bar::something has the same signature.
    c_api_set_callback(call_member<Bar, &Bar::something>, this);
}

I’m quite pleased with that. Now we have a simple bit of template goodness which we can use every time we need to convert some member function with signature void (Class::*)(int) into a free function with signature void (*)(int, void*) which can be used as a callback with C libraries. It’s just a few lines of code but can do so much for us. We could however get it to do even more for us… We could generalise the return type and the number and types of the arguments. I’ll leave these for another day.

C to member function callbacks – version 4

Finally, the invocation of call_member<> is now quite long, and includes the name of the class twice: once by itself, and once as part of the member function pointer used as a non-type template parameter. We can shorten this a little by using an auto template parameter for the member function pointer. The following code adds a thin wrapper for the c_api_set_callback() function.

// C-style API taking a plain function pointer and
// void pointer context
using Callback = void (*)(int x, void* context);
void c_api_set_callback(Callback cb, void* context);

// Template the member function pointer type alias.
template <typename Class>
using MemFuncPtr = void (Class::*)(int);

// Trampoline to redirect C callback to a member function
template <typename Class, MemFuncPtr<Class> mem_func_ptr>
void call_member(int x, void* context)
{
    auto obj = static_cast<Class*>(context);
    (obj->*mem_func_ptr)(x);
}

// Wrapper for c_api_set_callback which means we don't have
// to pass the name of the class twice.
template <auto MemFuncPtr, typename Class>
void new_c_api_set_callback(Class* context)
{
    // This is the code we called directly in Foo::Foo() before.
    c_api_set_callback(call_member<Class, MemFuncPtr>, context);
}

struct Foo
{
    Foo();
    void alpha(int x);
    void beta(int x);
    void gamma(int x);
    void delta(int x);
};

Foo::Foo()
{
    // Now we just pass the the member function pointer and
    // write the name of the class only once.
    new_c_api_set_callback<&Foo::alpha>(this);
    new_c_api_set_callback<&Foo::beta>(this);
    new_c_api_set_callback<&Foo::gamma>(this);
}

The trick here is that the new template function takes a Class* argument instead of a void* argument. This is sufficient for the compiler to work out the type of class for which MemFuncPtr is a member function pointer. This happens at the point where we actually call the template function in Foo::Foo(). This all adds up to needing to pass one less template argument when setting the callback function. We don’t have to duplicate the name of the class, which is convenient. A call to new_c_api_set_callback() is now basically the same amount of typing as a call to c_api_set_callback() would be with a free function. I don’t regard brevity as a particularly important goal, but do value clarity. It’s hard not to like the simplicity of using this template.

Of course, using this method also adds up to generating a distinct version of new_c_api_set_callback() each time the function template is used. Is it a price worth paying? Once again, they are very small functions. In fact, in this example they optimised away completely. The compiler can do this easily because there are no tricksy function pointers which can’t be resolved. The template function is little more than a typesafe macro.

Conclusion

Pointers to member functions are a fascinating topic, and they are quite useful in some situations. I hope that this article managed to shed a little light on them and maybe demonstrate that they are not one of the dark arts, but actually relatively simple to understand.

It is common, especially in embedded code, to set callback functions using existing C APIs. I showed a simple way to interface your C++ classes with C callbacks, and then progressively generalised that method to make it more useful while avoiding the need to write a lot of repeated code.

In the next article, I will take some of these ideas and generalise the concept of callback functions to C++.

Function pointers are a commonly used feature of both C and C++, though perhaps to a lesser extent in C++ because some of the use cases are obviated by other language features. They seem to be the cause of some confusion, especially among beginners, so I thought it might be useful to go through a detailed introduction. If you are already comfortable with function pointers, I doubt you will learn much here, though I’d be interested in feedback on how to improve the content. Or perhaps have a look at member function pointers.

The following code is a simple example of using function pointers to get the ball rolling:

// Declare a function pointer **type**, FuncPtr, with
// signature int(*)(int).
using FuncPtr = int (*)(int);

// Define some simple functions.
int square(int x) { return x * x; }
int cube(int x)   { return x * x * x; }
int fourth(int x) { return x * x * x * x; }

int test(int x, int power)
{
    // Declare a function pointer **variable**, func_ptr.
    FuncPtr func_ptr;

    // Take the address of one of the functions.
    switch (power)
    {
        case 3:  func_ptr = cube;   break;
        case 4:  func_ptr = fourth; break;
        default: func_ptr = square;
    }

    // Call whichever function was selected.
    return func_ptr(x);
}

Aside: Although it may seem odd at first, functions have addresses. The compiled code is just a bunch of bytes, and must live somewhere in the software’s address space. Calling the function amounts to setting the processor’s program counter to this address. There is more to do in order to pass arguments, save the current processor state, and the like, but that’s the core idea.

Functions have types

To understand function pointers, I think it may be useful to consider function types a little. Every function has a function type associated with it which is derived from the return type and the argument types. For example, a function whose prototype is void foo(int x, double y) has a type of void(int,double) – you literally just remove the function name and argument names.

• The function void bar(int alpha, double beta) has the same type as foo.
• The member function void Class::member(int a, double b) has the same type.
• The function int baz(int x, int y, int z) has a different type, which is int(int,int,int).

A function type is somewhat like a data type such as int, but you can’t do a lot with it. You can’t even declare variables of a function type. What would they even be? I guess they’d be whole functions. Although I have never seen this in practice, you can create an alias for a function type and use it to declare functions. Like this:

// Alias for a function type
using FuncType = void(int, double);

// Equivalent to void gamma(int, double);
FuncType gamma;

// Equivalent to void delta(int, double);
FuncType delta;

struct Thing
{
    // Equivalent to void member(int, double);
    FuncType member;
};

The alias can be used to declare functions but not to define them. So to implement Thing::member you need to write this:

void Thing::member(int, double)
{
}

This is quite an obscure corner of the language which I’m only including for background. I would definitely avoid doing anything directly with function types like the examples just given: you will just confuse everyone. Note that my description of function types is very informal compared to the C and C++ standards. You should check those for full details. But I think I’ve covered enough for our purposes.

Function pointers = pointers to function types

I said above that you can’t declare variables of function type. However, what you can do is declare variables whose type is pointer to function type: these are function pointers. In much the same way as data pointers hold the addresses of data objects, function pointers hold the addresses of functions. Function pointers are much more interesting and useful than function types.

Sadly, declaring function pointers is not pretty. You already know this, but to declare a variable of type pointer to int or pointer to double, you just do this:

// x is a variable of type pointer to int
int* x;

// y is a variable of type pointer to double
double* y;

Simple enough. To declare a variable of a pointer to function type such as void(int,double) you have to use some quite ugly and confusing syntax:

// fizz is a variable of type
// pointer to void(int,double)
void (*fizz)(int, double);

// buzz is a variable of type
// pointer to int(int,int,int)
int (*buzz)(int, int, int);

Both fizz and buzz are function pointers. The names of these variables are mixed into the signatures when declaring them. This is often a source of great confusion. I think this might be my candidate for the ugliest syntax in all of C and C++. We will shortly simplify these declarations…

Even though both fizz and buzz are function pointers, it is important to understand that they have completely distinct data types. They are as distinct as x and y above, an int* and a double*, respectively.

• Function pointers are data types. They may be null, or may hold the address of a function which has a matching signature (i.e. a matching function type).
• Function pointers can be used in all the same places as other data types: as local variables, as members of structs and classes, in arrays, in STL containers, allocated on the heap (I’ve never seen this), as non-type template parameters, and so on.
• Function pointers can also be used in expressions with comparison and boolean operators but, unlike data pointers, arithmetic and bitwise operators make no sense and are illegal in C++.
• A function pointer type itself can also be used as a template parameter.

So that has hopefully cleared up what function pointers are. The basic syntax for declaring them is just horrible. So…

Aliases for function pointer types

This section looks at how to use aliases to make function pointer declarations look just like other variable declarations. There a few common ways to alias a function pointer type.

Typedef

The first is inherited from C and is something you should become familiar with even though I don’t recommend using it in your own code. You will see it a lot in older C++ code, and it is the only method available in C. This method creates an alias with typedef. The syntax is exactly the same as declaring a variable above, but with the keyword typedef in front:

// Old style function pointer **type** - avoid.
typedef void (*OldFuncPtr)(int, double);

// ptr is a function pointer.
OldFuncPtr ptr;

// vec is a vector of function pointers.
std::vector<OldFuncPtr> vec;

// Thing::m_ptr is a function pointer.
// (*NOT* a pointer to a member function, but
// a plain function pointer which is a data
// member.)
class Thing
{
    OldFuncPtr m_ptr;
};

// func is a non-type template parameter for
// class Something.
template <OldFuncPtr func>
class Something {};

The code includes a few use cases for OldFuncPtr to demonstrate (I hope) that using the alias is simpler than using the raw function pointer syntax. We could, for example, have defined vec as follows, which is equivalent. You will sometimes see code like this, but I know which I prefer:

// vec is a vector of function pointers.
std::vector<void(*)(int, double)> vec;

Type alias

A typedef gives a more user friendly name to a function pointer type, but still uses the old C syntax when creating the alias. C++11 introduced a better type alias with the using keyword:

// New style function pointer type - preferred.
using NewFuncPtr = void (*)(int, double);

This pulls the alias name of the function pointer type out from the middle of the signature and is, I think, a lot more readable. The code basically just says “this simple name is equivalent to this ugly thing”. NewFuncPtr is identical to OldFuncPtr and they can be used interchangeably. The parentheses around the star are required because of operator precedence – to distinguish our function pointer from a function type which returns void* in this example. I generally just read “(*)” as “pointer to function”.

Something to note is that type aliases can be templates. Like this:

template <typename T>
using FuncPtrT = void (*)(T, T);

// fi is a function pointer of type
// void (*)(int, int).
FuncPtrT<int> fi;

// fd is a function pointer of type
// void (*)(double, double).
FuncPtrT<double> fd;

This can be very useful sometimes. For completeness, if we wish, we can also alias this template for particular template parameters:

using IntFuncPtr = FuncPtrT<int>;

// fi2 is a function pointer of type
// void (*)(int, int).
IntFuncPtr fi2;

Trailing return type

C++ introduced a variation on how to declare a function. The return type can come at the end instead of at the beginning. This is useful/essential when the return type is not known before the argument types are known to the compiler, which can happen in some templates. The trailing syntax looks like this:

// New style function pointer type - trailing return.
using TrailingFuncPtr = auto (*)(int, double) -> void;

TrailingFuncPtr is identical to OldFuncPtr and NewFuncPtr, and they can be used interchangeably. auto is required at the start as a stand-in for the return type, and the actual return type comes at end after an arrow ->.

Some people now use the trailing syntax everywhere in their code for “consistency”. Personally, I don’t recommend this. I’m all for modernising code, but this seems to be gratuitously throwing away forty years of familiarity with billions of lines of code for zero gain. Change for change’s sake is not a good thing.

On the other hand, the trailing syntax does have a nice feature in this particular context. You can read the function pointer meaning directly from left to right: “TrailingFuncPtr is a pointer to a function which takes two arguments with types int and double, respectively, and returns void“. That’s much simpler than the C syntax, which bounces from going left to right to left again.

Using a function pointer alias

I have never seen this used anywhere, but we could theoretically declare an alias for a function type rather than a pointer to function type, and then declare pointers of that type. Like this:

// Alias for a function type
using FuncType = void(int, double);

// This is a pointer to functions with type
// void(int,double).
FuncType* func_ptr;

// Alias for a function pointer type
using FuncTypePtr = FuncType*;

// This is a pointer to functions with type
// void(int,double).
FuncTypePtr func_ptr2;

In this example, func_ptr and func_ptr2 have exactly the same data type. Given its apparent rarity, I’d probably avoid aliasing function types directly.

Using a function pointer variable

So far we have covered what function pointers are and how to alias them with simple names to hide the rather unpleasant syntax, but we haven’t actually used them for any function pointing. This is very simple: you just assign the function pointer with (the name of) a function, or its address, or the value of another function pointer, and then you use the function pointer to call the function of whose address it currently holds:

void cube(int x)
{
    std::cout << x << " cubed is " << (x*x*x);
}

void square(int x)
{
    std::cout << x << " squared is " << (x*x);
}

// Create an alias for the function pointer.
using FuncPtr = void (*)(int);
using DiffPtr = void (*)(int, int);

int main()
{
    FuncPtr ptr = &cube;
    ptr(3); // Calls cube(3)

    ptr = nullptr;
    ptr(3); // Nothing to call - crash

    ptr = square; // & optional
    ptr(5); // Calls square(5)

    FuncPtr ptr2 = ptr;
    ptr2(6); // Calls square(6)

    DiffPtr diff; // Uninitialised
    diff = cube;  // Doesn't compile
    diff = &cube; // Doesn't compile
    diff = ptr;   // Doesn't compile
}

Key things to note from the code in main():

• Function pointers can be null or uninitialised.
• Function pointers can be assigned and re-assigned
  • They can be directly assigned with the name of a function. This is analogous to assigning an int variable with an immediate value: “int x; … x = 42;”.
    • One of the curiosities of C (which C++ inherited) is that you can assign the function name directly, or take the address of the name with &. These are equivalent, and the compiler takes the address in both cases. I guess a function has no value that can be returned, so it makes sense to return its address instead.
  • They can be assigned to/from other function pointer variables. This is analogous to assigning an int variable with the value of another int variable: “int x, y; … x = y;”.
    • Note that using & on another function pointer will not work: this returns a pointer to a pointer to a function, which makes sense. Fear not – your code will not compile if you do this.
  • Function pointers cannot be assigned with a function name (or function pointer) which does not have the same signature. This is analogous to not being able to assign a variable of type Foo to a variable of type Bar (operator overloading notwithstanding).
    • This makes sense if you think about it. If the function at some address expects two integers arguments to be passed to it then it will almost certainly break if you call it through a function pointer which passes a double or something. Arguments are placed on the stack before jumping to the function’s address: the function knows how to unpack its arguments from the stack. If something else is there instead, there will be trouble.
• Function pointers are used with exactly the same function call syntax as a regular function with the signature they represent.
  • You can think of () as an operator which, when applied to a function pointer, calls the function which is being pointed at.
  • In fact, it turns out that () actually is an operator, and one that classes can overload with custom implementations. This is for another day.

Function pointers v data pointers

When you think about it, a function pointer seems a lot like a data pointer.

• Data resides in memory at some particular location in the software’s address space, and can be accessed by de-referencing a data pointer which holds that location (that is, the address of the data). The address of the data is the value of the data pointer.
• By the same token, executable code resides in memory at some particular location in the software’s address space, and can be executed by placing that location (that is, the address of the function) into the processor’s program counter. The address of the function is the value of the function pointer.

It’s a nice analogy, but it’s a mirage. Data pointers and function pointers are not really the same thing, and they are not at all interchangeable. They are not even necessarily the same size (on Cortex-M, both are four bytes). Depending on the architecture, functions may not even reside in the same address space as data. That is, you could theoretically have both data with address 0x00020000 and a function with address 0x00020000, but with no overlap because they are in independent address spaces (for example, Harvard architecture devices).

So if you ever find yourself casting a data pointer into a function pointer, or vice versa: your code is probably broken. It might work if you call the function, depending on the architecture and the implementation, and/or it might start a game of Global Thermonuclear War. I’m no language lawyer, but it is also questionable whether casting between function pointers with different signatures is well-defined. Remember: casting is lying to the compiler. Or, if you prefer, it is saying to the compiler “Look away! I totally know what I’m doing”. Which is very often the same thing in my experience.

But still, when it comes right down to it, they are both just data types whose variables hold addresses, which are just numbers. Function pointers are not mysterious black magic, and that’s good to know.

Why are function pointers useful?

We’ve covered what function pointers are and how to use them a little bit, so now let’s finally look at some ways they are used in practice. Function pointers offer a simple indirection mechanism that can be used in many different ways to call a function whose identity is not necessarily known at compile time. We already saw an example of this in the function test() at the beginning of this article. The following sections demonstrate a few more examples.

Lookup table

Lookup tables are very common. One example might be in the implementation of a finite state machine. If all the action functions have the same signature, they could be stored in a table which is indexed by the current state and the current event. Or we could have something as simple as this:

// Declare a function pointer type.
using Func = int (*)(int);

// Define some simple functions.
int square(int x) { return x * x; }
int cube(int x)   { return x * x * x; }
int fourth(int x) { return x * x * x * x; }

// A lookup table of function pointers.
Func g_table[] = { square, cube, fourth };

int test(int x, int index)
{
    assert(index < 3);
    return g_table[index](x);
}

Virtual functions are typically implemented internally using a table of function pointers: the vtable. The compiler does not know which implementation of a given virtual function you will call at run time, but it does know the index of that function in the vtable. So calling a virtual function involves a simple lookup in a table with a compile time constant index to find a function pointer. A lot of people seem to think virtual functions are very expensive. This is not directly true, but they can have an impact on cache hits, and cannot easily be optimised away. But if you actually need run time polymorphism, it could hardly be more efficient. [Note that I am glossing over the fact that virtual functions are member functions, and that pointers to member functions are not at all the same creatures as pointers to free functions. The compiler knows its business.]

Interface structure

I’ve often seen structures containing a set of function pointers which collectively provide an interface to some behaviour. This can be used in C to sort of modularise code. The client of the interface specifies what the functions do, but has no idea how they are implemented. An instance of the structure is populated somewhere during initialisation, and may even change during program execution. You almost never see code like this in C++ because this is a perfect use case for virtual functions in abstract base classes.

// Create instance of structure and populate somewhere.
struct Funcs
{
    // Direct signature usage to avoid three typedefs - lazy!
    void (*fiddle)(int);
    void (*faddle)(int, int);
    void (*muddle)(int, int, int);
    // ...
};

// Funcs likely passed as a pointer in C.
void test(int x, const Funcs& funcs)
{
    // Assume function pointers all non-null.
    funcs.fiddle(x);
    funcs.faddle(x, x);
    funcs.muddle(x, x, x);
}

Speaking of virtual functions, although they are always described as having function pointers in a “table”, the functions do not all have the same signature. I wonder if the reality is in principle more like the interface structure in the example here. But it really makes no difference since this is just a detail of the implementation. Function pointers are just numbers, and the implementation knows which function pointer type corresponds to each index in the table. I think it is safe to assume that the compiler knows how to make virtual functions work properly.

Callback functions

One of the most common idioms that uses function pointers is callback functions, so I’ll cover them in some detail.

Imagine that you are using a library which needs to notify your code when certain things happen. Perhaps it internally implements an interrupt handler for some GPIO input and your application needs to know when an interrupt occurs. You cannot easily replace the interrupt service routine with your own, but the library lets you set a callback function. It might be implemented like this:

// Library code
// ------------
// In the public header file
using IntHandler = void (*)(bool state);
void set_interrupt_handler(IntHandler handler);

// In the private implementation file
IntHandler g_handler = nullptr;
void set_interrupt_handler(IntHandler handler)
{
    g_handler = handler;
}

extern "C" void GPIO_IRQ_Handler()
{
    // Clear interrupt flags
    // ...

    // Read state of the pin
    bool state;
    // ...

    // Call the callback function
    if (g_handler)
    {
        g_handler(state);
    }
}

The library declares a function pointer type/alias and a function you can call in order to pass it the address of a matching function, which it will store in g_handler. You can now use this feature in your own code something like this:

// Your application code
// ---------------------
// This is the callback function. The
// signature matches IntHandler.
void on_interrupt(bool state)
{
    // Do something here
}

int main()
{
    // Configure the pin using the library.
    // Pass the callback function to the library.
    // ...
    set_interrupt_handler(on_interrupt);

    // ...
}

And now on_interrupt() is called by the library whenever an interrupt occurs. From the application’s point of view, it is trivial to implement. From the library’s point of view, it’s a bit more effort, but not much.

Using function pointers like this is a staple of C interfaces. As with the other examples, callbacks are used all over the place.

Passing context information to callback functions

It is very common in such C interfaces to pass a void* value along with the function pointer. The value of the void* is meaningless to the library but can be used to give your own code some context when the callback is actually called. You might, for example, pass the address of a struct which contains some state which is useful in your application. This idiom is so common in C code that you are certain to encounter it. So I’ll include the full code again. I’ll use C-style declarations this time:

// Library code
// ------------
// In the public header file - argument names optional but helpful
typedef void (*IntHandler)(bool state, void* context);
void set_interrupt_handler(IntHandler handler, void* context);

// Or, if the C dev hates other people they might not bother
// with the typedef at all. Don't do this in your code. I mean,
// seriously, writing code like this is the very definition of
// misanthropic:
void set_interrupt_handler(void (*handler)(bool, void*), void* context);

// In the private implementation file
// These two values might be placed in a struct to associate them.
IntHandler g_handler = nullptr;
void*      g_context = nullptr;

// Or, if the C dev hates other people ...
void (*g_handler)(bool state, void* context);

void set_interrupt_handler(IntHandler handler, void* context)
{
    g_handler = handler;
    g_context = context;
}

extern "C" void GPIO_IRQ_Handler()
{
    bool state;
    if (g_handler)
    {
        // Call the callback function, passing context.
        g_handler(state, g_context);
    }
}

And now for your application code:

// Your application code
// ---------------------
struct SomeInfo { /* ... */ };

void on_interrupt(bool state, void* context)
{
    // Do something here with the context
    SomeInfo* info = static_cast<SomeInfo*>(context);
    // ...
}

SomeInfo g_interrupt_info;

int main()
{
    // Configure the pin using the library.
    // Pass the callback function and context to the library.
    // ...
    set_interrupt_handler(on_interrupt, &g_interrupt_info);

    // ...
}

This is not much harder to use than the version without context, but gives your code more scope for disambiguation if the same callback is used more than once.

Conclusion

I hope I have managed to shed at least some light on the nature and uses of function pointers. For me, the notion that function signatures themselves are just simple data types was not made clear early on, and I think this would have been helpful to understand.

Although they are useful and interesting, and kind of essential reading in the embedded domain, function pointers are really a very C way of doing things. This is not entirely the case, but C++ offers other abstractions which are often simpler to use. Virtual functions are a good example: one of the main uses for function pointers in C is to create run-time polymorphism which is almost indistinguishable from virtual functions. The built-in C++ version is efficient, and offers the compiler better opportunities for optimisation. Callback functions are still very important, especially if you have to integrate your application with C, which is usually the case in the embedded world.

The next article will move on to the generalisation of function pointers in C++: member function pointers. These are way more fun!
